| Standards Met | UL Listed, CSA Certified, CCC Certified |
| Sensor Technology | Inductive |
| IP Rating | IP67 - dust tight; water immersion protected, IP69K - dust tight; close-range high-pressure hot water protected |
| Minimum Operating Temperature | -25 °C |
| Maximum Operating Temperature | 85 °C |
| Shielding | Unshielded |
| Reverse Polarity Protection | |
| Output Type | NO |
| Thread Size | M30 |
| Terminal Type | |
| Mounting Type | Flush |
| Housing Material | Plastic |
| Body Style | Barrel |
| Material Detected | Metal |
| Brand | Schneider Telemecanique |
| Detection Type | |
| Switching Mode | |
| Light Source | |
| Hazardous Area Certification | |
| Maximum Detection Range | 22 mm |
| Minimum Detection Range | 0 mm |
| Maximum DC Supply Voltage | 24 V |
| Minimum DC Supply Voltage | 12 V |
| Maximum AC output current | 300 mA |
| Electrical Connection | Cable |
| Dimensions | M30 x 60 mm |
| Length | 60 mm |
| Series | |
