Technical Specifications

Standards MetUL Certified, CE Marked, RCM Certified
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-30 °C
Maximum Operating Temperature55 °C
Reverse Polarity Protection
Output TypeNPN
Thread Size
Terminal Type3-Wire 2 m Cable
Mounting TypeCable Mount
Housing MaterialPlastic
Body StyleRectangular
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSchneider Telemecanique
Detection TypePolarised Reflex
Switching Mode
Light SourceInfrared
Hazardous Area Certification
Maximum Detection Range5000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage24 V
Minimum DC Supply Voltage12 V
Electrical ConnectionCable
Length20 mm
Width11 mm
Height34 mm
SeriesOsiSense XU
