Please note: Some technical details are unavailable for this product

Technical Specifications

Built-in Signal GeneratorNo
Power SourceUSB
Oscilloscope TypeMixed Signal
Input Impedance1 MΩ
Sample Rate16 GS/s
Display TypeWVGA
Calibrated service type
Record Length100 Mpts
Maximum Vertical Sensitivity5000 (mV/div)
Dimensions327 x 443 x 223 mm
BrandKeysight Technologies
Trigger TypePulse, Event, Time, Pattern/State, Edge, Edge Transition
Number of Channels8
Memory Depth100 Mpts
Battery Type
Waveform Refresh Rate000 wfm/s, 200
Safety CategoryIEC 61010-1:2017
Maximum Time Base1000 (s/div)
Digital/AnalogueAnalogue, Digital
Rise Time
Minimum Time Base100 (ns/div)
ManufacturerKeysight Technologies
Number of Analogue Channels8
Screen Size15.6 in
Weight14.50 kg
Bandwidth2500 MHz
Minimum Vertical Sensitivity1 (mV/div)
Manufacturer Part NumberEXR258A / -902
Waveform Math and AnalysisAdd, Divide, FFT, Multiply, Subtract
Touch ScreenYes
USB PoweredYes
Input Capacitance14 pF
Vertical Resolution10 bit
Oscilloscope FormBench
Number of Digital Channels16
Built-in Wave Generator
Communication InterfaceJTAG, SVID, UART, RS232, I2S
