| Built-in Signal Generator | No |
| Power Source | Mains |
| Oscilloscope Type | Digital Storage |
| Input Impedance | 1 MΩ |
| Sample Rate | 2.5 GS/s |
| Display Type | Capacitive Touch Gesture-Enabled Display |
| Calibrated service type | RSCAL |
| Record Length | 12.5 Mpts |
| Dimensions | 381 x 204 x 142 mm |
| Number of Automatic measurements | 37 |
| Brand | Keysight Technologies |
| Trigger Type | TV, Slew Rate, Logic, Qualified, Edge, Width, Glitch, Runt, Dropout, Interval |
| Number of Channels | 2 |
| Memory Depth | 12.5 Mpts |
| Battery Type | |
| Wi-Fi | No |
| Waveform Refresh Rate | 00, 1, 000 wfm/s |
| Safety Category | CAT I, CAT II |
| Maximum Time Base | 50 (s/div) |
| Digital/Analogue | Digital |
| Rise Time | 1 ns |
| Minimum Time Base | 2 (ns/div) |
| Manufacturer | Keysight Technologies |
| Number of Analogue Channels | 2 |
| Screen Size | 12.1 in |
| Weight | 5.9 kg |
| Bandwidth | 350 MHz |
| Manufacturer Part Number | DSOX3032G |
| Waveform Math and Analysis | Floor, Invert, Trend, Product, Averaging, Sum, Difference, Envelope, Rescale, Square, Roof, Square Root, Derivative, Enhanced Resolution, Integral, Ratio, Reciprocal, Absolute Value, Zoom and FFT |
| Touch Screen | Yes |
| USB Powered | No |
| Input Capacitance | 8 pF |
| Vertical Resolution | 12 bit |
| Oscilloscope Form | Bench |
| Number of Digital Channels | 16 |
| Built-in Wave Generator | No |
| Communication Interface | LIN, CAN, IIC, USB, RS422, UART, RS232, RS485, SPI |
