Technical Specifications

AttributeValue
Thread Size
Terminal Type0.5 to 50 cm Cable
Mounting TypeScrew Mount
Housing MaterialDie-Cast Zinc
Body StyleRectangular
Standards MetCE Marked
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeNPN
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandOmron
Detection TypeBackground Suppression
Switching ModeLight/Dark switching
Light SourceInfrared
Hazardous Area Certification
Maximum Detection Range500 mm
Minimum Detection Range5 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable
Dimensions54.5 x 40 x 44.7 mm
Length40 mm
Width44.7 mm
Height54.5 mm
SeriesE3S
