Technical Specifications

AttributeValue
Output TypePNP
Maximum Operating Temperature55 °C
Maximum DC Voltage24 V
Minimum Operating Temperature-25 °C
IP RatingIP67
Detection Range300 mm
Standards Met
Mounting Type
Thread Size
Terminal Type
Housing MaterialDie Cast Zinc
Body StyleRectangular
ManufacturerOmron
Optical TechnologyPhototransistor
Detection TypeRetro-reflective
SeriesE3S
Sensor TypeBlock
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandOmron
Communication Interface
Response Time1 ms
Electrical Connection3 Wire Cable 2 m
