Technical Specifications

AttributeValue
Standards MetCE Marked
Thread Size
Terminal Type2 m Cable
Mounting TypeScrew Mount
Housing MaterialDie-Cast Zinc
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandOmron
Detection TypeDiffuse
Switching ModeLight/Dark switching
Light SourceInfrared
Hazardous Area Certification
Maximum Detection Range2000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable
Dimensions32.2 x 20 x 57 mm
Length57 mm
Width20 mm
Height32.2 mm
SeriesE3S
