Technical Reference

Technical Specifications

AttributeValue
Mounting Type
Thread Size
Terminal TypeConnector M8 - 4 Pin
Housing MaterialPBT
Body StyleRectangular
Standards Met
Output TypePNP
Maximum Operating Temperature55 °C
Maximum DC Voltage26.4 V
Minimum Operating Temperature-10 °C
IP RatingIP67
Detection Range
ManufacturerOmron
Optical TechnologyLaser, Phototransistor
Detection TypeRetro-reflective
SeriesE3Z
Sensor TypeBlock
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandOmron
Communication Interface
Response Time1 ms
Electrical ConnectionM8 4 Pin Connector
