Technical Specifications

AttributeValue
Thread Size
Terminal Type7 m Cable
Mounting TypeScrew Mount
Housing MaterialPlastic
Body StyleRectangular
Standards MetCE Marked
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeNPN
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandOmron
Detection TypeThrough Beam
Switching ModeLight/Dark switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range7000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable
Dimensions22.3 x 12.4 x 44 mm
Length44 mm
Width12.4 mm
Height22.3 mm
SeriesE3S
