Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-40 °C
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerOmron
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max32 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload Protection
Length39 mm
Switching Frequency Max0.5 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
