Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal TypeCable
Housing MaterialStainless Steel
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerOmron
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance1.2 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length25.1
Switching Frequency Max4 kHz
Dimensions
Width4
Electrical ConnectionCable
