Technical Specifications

AttributeValue
Standards MetUL Listed, CE Marked, CSA Certified
Sensor TechnologyInductive
IP RatingIP67G - dust tight; water immersion protected & cutting oil resistant, IP67 - dust tight; water immersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature85 °C
ShieldingShielded
Reverse Polarity ProtectionYes
Output TypePNP
Thread SizeM12
Terminal Type5 m Cable
Mounting TypeQuasi-Flush
Housing MaterialNickel-Plated Brass
Body StyleBarrel
Material DetectedMetal
BrandOmron
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range4 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable
DimensionsM12 x 60.3 mm
Length60.3 mm
SeriesE2E-NEXT
