Technical Specifications

AttributeValue
Sensor TechnologyInductive
IP RatingIP67 - dust tight; water immersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature85 °C
ShieldingShielded
Reverse Polarity ProtectionYes
Output TypeNPN
Standards MetUL Listed, CE Marked, CSA Certified
Thread SizeM8
Terminal Type3-Pin M8 Connector
Mounting TypeFlush
Housing MaterialStainless Steel
Body StyleBarrel
Material DetectedMetal
BrandOmron
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range2 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
DimensionsM8 x 49 mm
Length49 mm
SeriesE2E-NEXT
