Technical Specifications

AttributeValue
Standards MetUL Listed, CE Marked, CSA Certified
Sensor TechnologyInductive
IP RatingIP67 - dust tight; water immersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature85 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Thread SizeM12
Terminal TypeM12 Connector
Mounting TypeNon-Flush
Housing MaterialNickel-Plated Brass
Body StyleBarrel
Material DetectedMetal
BrandOmron
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range5 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
DimensionsM12 x 48 mm
Length48 mm
SeriesE2E-NEXT
