Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25
IP RatingIP67G, IP69K, IP67
Reverse Polarity ProtectionYes
ManufacturerOmron
Shape
SeriesE2E-NEXT
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max30 V
Application
Communication InterfaceIO-LINK
Sensing Distance16 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current16 mA
Short Circuit Overload ProtectionYes
Length47.1
Switching Frequency Max
Dimensions
Width12
Electrical Connection4-Pin M12 Connector
