Omron Inductive Sensor M18 10mm NPN NO M12 E2EW-X10C118-M1TJ 0.3M

0 in stock

£100.80(exc. VAT)

£120.96(inc. VAT)

Mfr part no: E2EW-X10C118-M1TJ 0.3M

RS Stock No.: 2019692

Brand: Omron

Technical Reference

Attribute	Value
Standards Met	UL Listed, CE Marked, CSA Certified
Thread Size	M18
Terminal Type	4-Pin M12 Connector
Mounting Type	Flush
Housing Material	Stainless Steel
Body Style	Barrel
Sensor Technology	Inductive
IP Rating	IP67 - dust tight; water immersion protected
Minimum Operating Temperature	0 °C
Maximum Operating Temperature	85 °C
Shielding	Shielded
Reverse Polarity Protection	Yes
Output Type	NPN
Material Detected	Metal
Brand	Omron
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range	10 mm
Minimum Detection Range	0 mm
Maximum DC Supply Voltage	30 V
Minimum DC Supply Voltage	10 V
Electrical Connection	Connector
Dimensions	M18 x 30 mm
Length	30 mm
Series	E2EW
