Technical Specifications

AttributeValue
Standards MetUL Listed, CE Marked, CSA Certified
Thread SizeM30
Terminal Type4-Pin M12 Connector
Mounting TypeFlush
Housing MaterialStainless Steel
Body StyleBarrel
Sensor TechnologyInductive
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature0 °C
Maximum Operating Temperature85 °C
ShieldingShielded
Reverse Polarity ProtectionYes
Output TypeNPN
Material DetectedMetal
BrandOmron
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range22 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
DimensionsM30 x 30 mm
Length30 mm
SeriesE2EW
