Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type4-Pin M12 Connector
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67G, IP69K, IP67
Reverse Polarity ProtectionYes
ManufacturerOmron
Shape
SeriesE2E-NEXT
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max30 V
Application
Communication InterfaceIO-LINK
Sensing Distance22 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current16 mA
Short Circuit Overload ProtectionYes
Length60.3
Switching Frequency Max0.2 kHz
Dimensions
Width30
Electrical Connection4-Pin M12 Connector
