Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type4-Pin M12 Connector
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25 °C
IP RatingIP67G, IP69K, IP67
Reverse Polarity ProtectionYes
ManufacturerOmron
Shape
SeriesE2E-NEXT
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max30 V
Application
Communication InterfaceIO-LINK
Sensing Distance22 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current16 mA
Short Circuit Overload ProtectionYes
Length60.3 mm
Switching Frequency Max0.2 kHz
Dimensions
Width30 mm
Electrical Connection4-Pin M12 Connector
