Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread Size
Terminal Type3-Pin M8 Connector
Housing MaterialABS
Body StyleRectangular
Supply Voltage12 V to 24 V
Output TypeNPN
Maximum Operating Temperature55 °C
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-10 °C
IP RatingIP66
Reverse Polarity ProtectionYes
ManufacturerOmron
Shape
Series
Depth10.1 mm
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance10 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload Protection
Length50 mm
Switching Frequency Max0.1 kHz
Dimensions50 x 20 x 10.1 mm
Width20 mm
Electrical Connection3-Pin M8 Connector
