Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread Size
Terminal Type0
Housing MaterialABS
Body StyleRectangular
Supply Voltage10 V to 30 V
Output TypeNPN
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerOmron
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance3 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload Protection
Length27 mm
Switching Frequency Max0.6 kHz
Dimensions
Width10 mm
Electrical Connection
