Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread Size
Terminal TypeCable
Housing MaterialPolyarylate
Body StyleRectangular
ManufacturerOmron
Shape
Series
Depth8.4 mm
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance2.5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current50 mA
Short Circuit Overload Protection
Length23 mm
Switching Frequency Max1 kHz
Dimensions23 x 8.9 x 8.4 mm
Width8.9 mm
Electrical ConnectionCable
