Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialNickel Plated Brass
Body StyleCylindrical
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-40
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerOmron
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandOmron
Supply Voltage DC Max32 V
Application
Communication Interface
Sensing Distance16 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload Protection
Length39
Switching Frequency Max0.4 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
