Technical Specifications

AttributeValue
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected, IP69 - dust tight; high-pressure hot water protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature60 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Thread Size
Terminal Type4-Pin M12 Connector
Mounting TypeScrew Mount
Housing MaterialPlastic
Body StyleRectangular
Standards MetECOLAB Certified, cULus Certified
Material DetectedPlastic - Transparent, Glass - Transparent, Metal
BrandOmron
Detection TypeRetroreflective
Switching ModeLight/Dark switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range4500 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions48.5 x 15.8 x 40.5 mm
Length40.5 mm
Width15.8 mm
Height48.5 mm
SeriesE3S
