Technical Specifications

AttributeValue
Thread Size
Terminal Type2 m Cable
Mounting TypeScrew Mount
Housing MaterialStainless Steel
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-10 °C
Maximum Operating Temperature50 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeNPN
Standards MetUL Certified, CE Marked
Material DetectedPlastic - Transparent, Glass - Transparent, Metal
BrandOmron
Detection TypeDiffuse with Background Suppression
Switching Mode
Light SourceLaser
Hazardous Area Certification
Maximum Detection Range150 mm
Minimum Detection Range35 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable
Dimensions12.7 x 30.4 x 47 mm
Length47 mm
Width12.7 mm
Height30.4 mm
SeriesE3AS
