Technical Specifications

Thread SizeM8
Terminal TypeM8 Connector
Mounting TypeScrew Mount
Housing MaterialStainless Steel
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67G - dust tight; water immersion protected & cutting oil resistant, IP67 - dust tight; water immersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
Reverse Polarity Protection
Output TypeNPN
Standards MetUL Certified, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
Detection TypeDiffuse with Background Suppression
Switching Mode
Light SourceLED
Hazardous Area Certification
Maximum Detection Range80 mm
Minimum Detection Range10 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions11.4 x 37.9 x 22 mm
Length37.9 mm
Width11.4 mm
Height22 mm
