Technical Specifications

AttributeValue
Thread Size
Terminal Type2 m Cable
Mounting TypeScrew Mount
Housing MaterialPlastic
Body StyleFork
Sensor TechnologyPhotoelectric
IP RatingIP64 - dust tight; slashing water protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeNPN
Standards MetcULus Listed, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandOmron
Detection TypeThrough Beam
Switching ModeLight/Dark switching
Light SourceInfrared
Hazardous Area Certification
Maximum Detection Range25 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage24 V
Minimum DC Supply Voltage12 V
Electrical ConnectionCable
Dimensions11 x 40 x 50 mm
Length50 mm
Width40 mm
Height11 mm
SeriesE3Z
