Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM8 x 1
Terminal TypeMale Thread Socket
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity Protection
ManufacturerOmron
Shape
SeriesE2E-NEXT
Hazardous Area Certification
Standards/ApprovalsUL Certified, CSA C22.2 No.14-13, CE Certified, UL 508
BrandOmron
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance3 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length37.8
Switching Frequency Max0.25 kHz
Dimensions
Width15
Electrical ConnectionMale Thread Socket
