Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM12 x 1
Terminal TypeMale Thread Socket
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity Protection
ManufacturerOmron
Shape
SeriesE2E-NEXT
Hazardous Area Certification
Standards/ApprovalsUL Certified, CSA C22.2 No.14-13, CE Certified, UL 508
BrandOmron
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance7 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length47.1 mm
Switching Frequency Max0.25 kHz
Dimensions
Width21 mm
Electrical ConnectionMale Thread Socket
