Technical Specifications

Sensor TechnologyInductive
IP RatingIP40 - objects >1mm; not water protected
Minimum Operating Temperature-20 °C
Maximum Operating Temperature60 °C
Reverse Polarity Protection
Output Type
Standards MetEN60947-5-2, IEC 60529
Thread Size
Terminal Type1 m Cable
Mounting TypeSurface Mount
Housing MaterialPlastic
Body StyleRectangular
Material Detected
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range15 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage100 V
Minimum DC Supply Voltage0 V
Maximum AC output current100 mA
Electrical ConnectionTerminal Block
Dimensions14 x 14 x 50 mm
Length14 mm
Depth14 mm
Height50 mm
