Technical Reference

Technical Specifications

AttributeValue
Standards Met
Output TypePNP
Maximum Operating Temperature55
Maximum DC Voltage26.4 V
Minimum Operating Temperature-10
IP RatingIP67
Detection Range7000 mm
Mounting Type
Thread Size
Terminal Type3-Wire Cable 2 m
Housing MaterialPBT
Body StyleRectangular
ManufacturerOmron
Optical TechnologyLaser, Phototransistor
Detection TypeRetro-reflective
SeriesE3Z
Sensor TypeBlock
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandOmron
Communication Interface
Response Time1 ms
Electrical Connection3 Wire Cable 2 m
