Technical Specifications

AttributeValue
Terminal Type
Supply Voltage24 V
Output TypePNP
ManufacturerOmron
Number of Beams36
FeaturesDownsized, No Torque Control Required, Ensuring Safe Restart, Easy Adjustment after Mounting, Protected with Protection Cover, Slim Housing, Robust & Compact Design, Smart Muting Actuator, Quick Troubleshooting, Reducing Stops Due to Mutual Interference, Used in Global & Harsh Environment, Reliable Even in Harsh Environment
SeriesF3SG-RE
Product Range
Response Time Max135 ms
BrandOmron
Protective Area Height750 mm
Sensing Distance Max20000 mm
Beam Resolution30 mm
Height750
Protection TypeFinger, Arm, Hand
Range
PL (EN ISO 13849-1)PL c
Length35
Maximum Protective Width
Sensing Distance Min300 mm
Component TypeSender, Receiver
Dimensions35 x 35 x 750 mm
Width35
Scanning Range
Safety Type2
SIL (IEC 61508)SIL 1
