Technical Specifications

AttributeValue
Standards MetCE Marked
Thread Size
Terminal Type2 m Cable
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandOmron
Detection TypeDiffuse
Switching Mode
Light SourceLED
Hazardous Area Certification
Maximum Detection Range200 mm
Minimum Detection Range10 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable
Dimensions21 x 12.4 x 44 mm
Length44 mm
Height12.4 mm
SeriesE3S
