Technical Specifications

AttributeValue
Thread Size
Terminal Type2 m Cable
Mounting TypeScrew Mount
Housing MaterialPlastic
Body StyleRectangular
Standards MetCE Marked
Sensor TechnologyPhotoelectric
IP RatingIP64 - dust tight; slashing water protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeRelay
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandOmron
Detection TypeDiffuse
Switching Mode
Light SourceLED
Hazardous Area Certification
Maximum Detection Range300 mm
Minimum Detection Range0 mm
Maximum AC Supply Voltage240 V
Minimum AC Supply Voltage24 V
Maximum DC Supply Voltage240 V
Minimum DC Supply Voltage24 V
Electrical ConnectionCable
Dimensions18 x 50 x 52 mm
Length52 mm
Width18 mm
Height50 mm
SeriesE3JK
