Technical Specifications

AttributeValue
Mounting Type
Thread Size
Terminal Type5-Wire Cable 2 m
Housing MaterialABS
Body StyleRectangular
Standards Met
Output TypeNO/NC
Maximum Operating Temperature55
Maximum DC Voltage240 V
Minimum Operating Temperature-25
IP RatingIP64
Detection Range6000 mm
ManufacturerOmron
Optical TechnologyInfrared LED
Detection TypeRetro-reflective
SeriesE3JK
Sensor TypeBlock
Maximum AC Voltage240 V
Light SourceInfrared LED
Maximum Current
Hazardous Area Certification
Switching Mode
BrandOmron
Communication Interface
Response Time20 ms
Electrical Connection5 Wire Cable 2 m
