Omron Sensor, SR 7M Thru-beamn PNP E3S-AT86

17 in stock

£242.30(exc. VAT)

£290.76(inc. VAT)

Mfr part no: E3S-AT86

RS Stock No.: 8210000

Brand: Omron

Technical Reference

Attribute	Value
Thread Size
Terminal Type	M12 Connector
Mounting Type	Screw Mount
Housing Material	Plastic
Body Style	Rectangular
Standards Met	CE Marked
Sensor Technology	Photoelectric
IP Rating	IP67 - dust tight; water immersion protected
Minimum Operating Temperature	-25 °C
Maximum Operating Temperature	55 °C
Shielding	N/A
Reverse Polarity Protection
Output Type	PNP
Material Detected	Metal, Plastic - Opaque, Glass - Opaque
Brand	Omron
Detection Type	Through Beam
Switching Mode	Light/Dark switching
Light Source	LED
Hazardous Area Certification
Maximum Detection Range	7000 mm
Minimum Detection Range	0 mm
Maximum DC Supply Voltage	30 V
Minimum DC Supply Voltage	10 V
Electrical Connection	Connector
Dimensions	21 x 12 x 50 mm
Length	50 mm
Width	12 mm
Height	21 mm
Series	E3S
