Technical Specifications

AttributeValue
Sensor TechnologyCapacitive
IP RatingIP66 - dust tight; heavy seas protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature70 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypeNPN
Standards MetCE Marked
Thread Size
Terminal Type2 m Cable
Mounting Type
Housing MaterialPlastic
Body StyleBarrel
Material DetectedPlastic - Transparent, Glass - Transparent, Metal, Plastic - Opaque, Plastic - Translucent, Glass - Opaque, Glass - Translucent
BrandOmron
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range25 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage24 V
Minimum DC Supply Voltage12 V
Maximum AC output current200 mA
Electrical ConnectionCable
Dimensions34 x 82 mm
Length82 mm
SeriesE2K-C
