| Built-in Signal Generator | Yes |
| Power Source | USB |
| Oscilloscope Type | Digital Storage |
| Input Impedance | 1 MΩ |
| Sample Rate | 0.080 GS/s |
| Display Type | |
| Calibrated service type | RSCAL |
| Record Length | 256 Mpts |
| Maximum Vertical Sensitivity | 10000 (mV/div) |
| Dimensions | 190 x 170 x 40 mm |
| Number of Automatic measurements | 15 |
| Brand | Pico Technology |
| Trigger Type | Window, Simple Edge, Pulse Width, Level Dropout, Window Dropout, Advanced Edge, Window Pulse Width, Runt, Interval |
| Number of Channels | 4 |
| Memory Depth | 256 Mpts |
| Battery Type | |
| Wi-Fi | |
| Waveform Refresh Rate | 100 wfm/s |
| Safety Category | EN 61010-1 |
| Maximum Time Base | 5000 (s/div) |
| Digital/Analogue | Digital |
| Rise Time | 150 ns |
| Minimum Time Base | 20 (ns/div) |
| Manufacturer | Pico Technology |
| Number of Analogue Channels | 4 |
| Weight | 0.55 kg |
| Bandwidth | 20 MHz |
| Minimum Vertical Sensitivity | 2 (mV/div) |
| Manufacturer Part Number | PicoScope 4424A |
| Waveform Math and Analysis | Functions, Operands |
| Touch Screen | No |
| USB Powered | Yes |
| Input Capacitance | 19 pF |
| Vertical Resolution | 12 bit |
| Oscilloscope Form | PC Based |
| Number of Digital Channels | 16 |
| Built-in Wave Generator | Yes |
| Communication Interface | USB |
