Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM18 x 1
Terminal TypeCable
Housing MaterialPBT
Body StyleCylindrical
Supply Voltage20 - 250 Vac
Output Type
Maximum Operating Temperature70
Sensor TechnologyCapacitive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity Protection
ManufacturerRS PRO
Shape
Series
Supply Voltage AC250 V
Hazardous Area Certification
Standards/Approvals
BrandRS PRO
Application
Communication Interface
Sensing Distance5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency15 Hz
Switching Current300 mA
Short Circuit Overload Protection
Length83.5
Switching Frequency Max
Dimensions
Electrical ConnectionCable
