Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM18 x 1
Terminal TypeCable
Housing MaterialCopper Alloy
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyCapacitive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerRS PRO
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandRS PRO
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency50 Hz
Switching Current15 mA
Short Circuit Overload ProtectionYes
Length91.5
Switching Frequency Max
Dimensions
Electrical ConnectionCable
