Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP NO
Maximum Operating Temperature55
Sensor TechnologyCapacitive
Shielding
Minimum Operating Temperature-10
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPBT
Body StyleRectangular
ManufacturerRS PRO
Shape
Series
Depth20
Hazardous Area Certification
Standards/Approvals
BrandRS PRO
Supply Voltage DC Max30 V
Application
Communication Interface
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current15 mA
Short Circuit Overload ProtectionYes
Length43
Switching Frequency Max0.060 kHz
Dimensions43 x 24 x 20 mm
Width24
Electrical Connection4-Pin M12 Connector
