Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature55
Sensor TechnologyCapacitive
Shielding
Minimum Operating Temperature-10
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPBT
Body StyleCylindrical
ManufacturerRS PRO
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandRS PRO
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance4 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency50 Hz
Switching Current15 mA
Short Circuit Overload ProtectionYes
Length69
Switching Frequency Max
Dimensions
Electrical Connection4-Pin M12 Connector
