Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyCapacitive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type4-Pin M12 Connector
Housing MaterialCopper Alloy
Body StyleCylindrical
ManufacturerRS PRO
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandRS PRO
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance10 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency50 Hz
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length79
Switching Frequency Max
Dimensions
Electrical Connection4-Pin M12 Connector
