Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type4-Pin M12 Connector
Housing MaterialNickel Plated Brass
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypeNPN
Maximum Operating Temperature75 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerRS PRO
Shape
Series
Hazardous Area Certification
Standards/ApprovalsUL Certified, cULus Listed, EN 60947-5-2, RoHS Compliant
BrandRS PRO
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance10 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length71 mm
Switching Frequency Max0.5 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
