Technical Reference

Technical Specifications

AttributeValue
Standards MetUL Certified, CE Marked, CSA Certified
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature70 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Thread Size
Terminal Type
Mounting TypeNon-Flush
Housing MaterialPlastic
Body StyleRectangular
Material DetectedMetal
BrandSchneider Telemecanique
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range25 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage24 V
Minimum DC Supply Voltage12 V
Maximum AC output current200 mA
Electrical ConnectionCable
Dimensions15 x 40 x 40 mm
Length15 mm
Depth40 mm
Height40 mm
Series
