Technical Reference

Technical Specifications

AttributeValue
Thread SizeM18
Terminal Type4-Pin M12 Connector
Mounting TypeNon-Flush
Housing MaterialStainless Steel
Body StyleBarrel
Standards MetcULus Certified
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature70 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Material DetectedMetal
BrandSchneider Telemecanique
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range20 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Maximum AC output current200 mA
Electrical ConnectionConnector
DimensionsM18 x 63.5 mm
Length63.5 mm
Series
