Technical Reference

Technical Specifications

AttributeValue
Standards MetUL Listed, CSA Certified, CCC Certified
Thread SizeM18
Terminal Type
Mounting TypeNon-Flush
Housing MaterialPlastic
Body StyleBarrel
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Material DetectedMetal
BrandSchneider Telemecanique
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range8 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage48 V
Minimum DC Supply Voltage12 V
Maximum AC output current200 mA
Electrical ConnectionCable
DimensionsM18 x 62 mm
Length62 mm
SeriesXS
