Technical Specifications

AttributeValue
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected, IP69K - dust tight; close-range high-pressure hot water protected
ShieldingShielded
Reverse Polarity Protection
Output TypeNO
Standards MetcULus Listed, CE Marked
Thread SizeM18
Terminal TypeScrew Terminal
Mounting TypeFlush
Housing MaterialNickel-Plated Brass
Body StyleBarrel
Material DetectedMetal
BrandSchneider Telemecanique
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range8 mm
Minimum Detection Range0 mm
Maximum AC Supply Voltage240 V
Minimum AC Supply Voltage24 V
Maximum DC Supply Voltage240 V
Minimum DC Supply Voltage24 V
Maximum AC output current300 mA
Maximum DC output current200 mA
Electrical ConnectionTerminal Block
DimensionsM18 x 62 mm
Length62 mm
SeriesXS
