Technical Specifications

AttributeValue
Thread Size
Terminal Type
Mounting TypeFlush
Housing MaterialPlastic
Body StyleRectangular
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature70 °C
ShieldingShielded
Reverse Polarity ProtectionYes
Output TypeNO
Standards MetUL Certified, C-Tick Certified, Ecolab Certified, CSA Certified
Material DetectedMetal
BrandSchneider Telemecanique
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range40 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage24 V
Minimum DC Supply Voltage12 V
Maximum AC output current100 mA
Electrical ConnectionCable
Dimensions80 x 26 x 80 mm
Length80 mm
Depth26 mm
Height80 mm
Series
