Technical Reference

Technical Specifications

AttributeValue
Standards MetUL Certified, CE Marked, CSA Certified
Sensor TechnologyPhotoelectric
IP RatingIP65 - dust tight; water jet protected, IP67 - dust tight; water immersion protected, IP30 - objects >2.5mm; not water protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP/NPN
Thread Size
Terminal TypeScrew Clamp Terminal
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSchneider Telemecanique
Detection TypeDiffuse with Background Suppression
Switching Mode
Light SourceInfrared
Hazardous Area Certification
Maximum Detection Range2000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage24 V
Minimum DC Supply Voltage12 V
Electrical ConnectionTerminal Block
Dimensions
SeriesXUX
